MI Line Motorized Single-Side Working Conveyor 7.3 Mtr (24)

Overview of MI Line Motorized Single-Side Conveyor 7.3 Mtr (24)

In this conveyor line, the PCB moves on a chain conveyor, guided at its edges. As the PCB progresses, operators sequentially insert designated components into their respective locations. By the end of the line, all components are inserted, and the board is ready for soldering. The PCB edges are securely guided, and the conveyor channels are adjustable to accommodate different PCB widths, ensuring smooth and precise handling.

Built with a durable aluminium (4040) or powder-coated steel frame, the MI Line offers an ergonomic working height (900 mm 25 mm), adjustable bin trays, and variable-speed control (0.751.7 m/min) powered by a 3-phase induction motor. Its ESD-safe design, fire-hazard-free construction, and operator-friendly features make it ideal for high-volume production environments, including automotive, medical device, and consumer electronics industries.

---

Key Features ofMI Line Motorized Single-Side Working Conveyor 7.3 Mtr (24)

• Single-Side Operation
  • Ideal for seamless integration with wave soldering machines.

• Chain Conveyor with Adjustable Channels
  • Adjustable PCB guide channels for handling PCBs of different sizes (50 mm 350 mm).

• Ergonomic & Operator-Friendly Design
  • Powder-coated steel work platformfor durability and stable handling.

• Precision Speed Control
  • Variable speed range 0.75 1.7 m/minfor optimal synchronization with component insertion and wave-soldering lines.
• IntegratedAC drive control panelfor easy adjustment.

• Integrated Safety Features
  • Power-failure interlock and MCB electrical protection ensure safe operations.

• Optimized Workflow Accessories
  • Adjustable bin traysfor organized component handling.
• IntegratedLED tube lighting(without wiring) for a well-lit working area.
• Steel display board for magnetic drawingsfor quick reference.

• Fire-Hazard-Free Build
  • Customization Options

    We provide extensive customization to ensure the conveyor integrates perfectly with your workflow, improves productivity, and maximizes operational efficiency.
    From adjusting dimensions to fine-tuning speed controls and adding operator-friendly features, the conveyor can be tailored for a wide range of industrial environments.

    • Length & Height:Customizable conveyor length (standard 7 m / 24) and adjustable height to fit your layout.

    • PCB Width:Adjustable guide channels accommodate PCB sizes from50 mm to 350 mm.

    • Structure Material:Choice ofaluminium (4040)for lightweight durability orpowder-coated steelfor added strength and corrosion resistance.

    • Speed Control:Fine-tuned speed adjustments to synchronize with different stages of assembly or soldering processes.

    • Lighting & Electrical Setup:Optional integrated wiring for LED lighting, power sockets, and tool connections.

    • Accessories:Add-ons like adjustable bin trays, tool sliders, magnetic display boards, and shelving to improve productivity and workflow organization.

    ---

    Applications of MI Line Motorized Single-Side Working Conveyor 7 Mtr (24)

    Its reliable chain conveyor, adjustable PCB channels, and ergonomic design ensure smooth and precise component handling, even in demanding manufacturing environments.
    From small-scale PCB assembly to high-volume industrial production, it provides dependable support across multiple industries.

    • Manual Component Insertion:Efficiently supports resistors, capacitors, connectors, and other through-hole components.

    • PCB Inspection & Testing:Offers stable and safe PCB transfer during critical quality control and inspection stages.

    • Wave-Soldering Preparation:Moves fully populated PCBs seamlessly from the MI line to the wave-soldering machine.

    • High-Precision Manufacturing:Suitable for automotive, consumer electronics, and medical device production where precision handling is essential.

    • ESD-Sensitive Assembly Lines:Protects sensitive components from static discharge during transfer and assembly.

    • Flexible Industrial Applications:Adapts to diverse workflows in electronics, aerospace, and other high-tech manufacturing sectors.

    ---

    Why Choose MI Line Motorized Single-Side Working Conveyor 7 Mtr (24) from Estovir Technologies

    WithEstovir Technologies, you gain a partner that delivers advanced engineering, robust quality, and excellent after-sales support tailored to your production needs.
    Our focus on operator comfort, product durability, and process efficiency makes the MI Line conveyor the preferred choice for leading manufacturers.

    • Proven Expertise:Backed by decades of experience inPCB assembly line automationwith successful installations across industries.

    • Operator-Centric Design:Ergonomically designed with organized bins, adjustable trays, and easy-to-use controls for maximum productivity.

    • Reliable & Durable Build:Manufactured using high-quality materials and components to ensure long-term, low-maintenance performance.

    • ESD-Safe & Fire-Resistant:Safeguards sensitive electronic components and complies with global safety standards.

    • Comprehensive Support:Full range of services, including installation, calibration, preventive maintenance, and quick spare-part availability.

    • Custom-Fit Solutions:Flexible customization options to align perfectly with specific production line requirements.

    ---

    Our Complete Conveyor Solutions

    MI Line Single Side:Compact single-sided conveyor for smooth and reliable PCB handling.

  • MI Line Double Side:Dual-sided configuration that maximizes throughput and saves production floor space.

• MI Line Module 2.4 Mtr.:Modular conveyor unit for flexible and easily expandable line setups.

• Insertion Work Station with Manual Free Flow Conveyor MPI 350:Ideal for manual insertion processes, ensuring effortless material flow.

• Work Table Conveyor:Ergonomic workstation conveyors with ESD-safe designs for operator safety and precision work.

• Cooling Conveyor:Specialized design for controlled cooling after soldering or reflow operations.

• SMD Line Conveyor 1000 mm:Compact conveyor engineered specifically for smooth transfer in SMD assembly lines.

• Work Station Conveyor:Integrated assembly workstation with customizable and adjustable features.

• Inlet Conveyor:Reliable entry-point conveyor for feeding PCBs and components into the assembly line.

WATCH PRODUCT DEMO:VIDEO

Durable and Efficient Structure

The MI Line Motorized Single-Side Working Conveyor is engineered with a strong chain-based structure, ensuring reliability and stability during intensive industrial operations. Its robust design handles heavy-duty applications, delivering consistent and trouble-free performance.


Adaptability Across Industrial Applications

Suited for a range of industrial environments, this conveyor features standard sizing and supports a variety of material types. Its adaptability makes it an ideal solution for warehousing, assembly lines, and production facilities requiring efficient materials transport.


Secure and Flexible Power Options

This conveyor accommodates a voltage range from 110 to 215 Volt, making it compatible with diverse power standards. The electric motor minimizes manual intervention while maximizing speed and productivity, enhancing workplace efficiency.
